Blue Sea Systems Solenoid ML 12V
SKU BLUE-7718
- Control Circuit Voltage
- 10.1 to 16.5V DC
- Control Circuit Connection
- Tinned Wire
- Nominal Voltage
- 12V DC
- Coil Function
- Auto-Releasing
- Mounting
- #10
- Amperage Operating Current
- 8mA when OFF; 13mA when ON
- Amperage Operating Current when changing state
- <7A (40 ms)
- Terminal Stud Torque
- 140 in-lb (15.82 Nm)
Stocked items typically ship the next business day from our US warehouse. 30-day returns on unused stocked items. Exclusions apply. Return policy · Shipping policy
Shopping as a guest. Sign in to save your cart and check out as a dealer.
About this product
Solenoid ML 12V. For applications where sustained control signals are needed to emulate a Normally Open relay with a lower current draw. Silver alloy contacts provide high reliability for switching live loads.
Key features
- For applications where sustained control signals are needed to emulate a Normally Open relay with a lower current draw
- Silver alloy contacts provide high reliability for switching live loads
- LED output to remotely indicate switch state - requires optional LED or Remote Control Contura Switch with integrated LED (included in retail package)
- 3/8"-16 tin-plated copper studs for maximum conductivity and corrosion resistance
- One-piece stainless flange nuts for safe and secure connections
- Label recesses for circuit identification
- Retail package includes Remote Control Contura Switch
For installation planning, check the manufacturer's ratings: control circuit voltage: 10.1 to 16.5V DC; nominal voltage: 12V DC; coil function: Auto-Releasing; mounting: #10.
Manufacturer part 7718. Confirm the circuit rating, mounting arrangement, and required accessories against the manufacturer specifications before selecting this part.
Manufacturer specifications
- Control Circuit Voltage
- 10.1 to 16.5V DC
- Control Circuit Connection
- Tinned Wire
- Nominal Voltage
- 12V DC
- Coil Function
- Auto-Releasing
- Mounting
- #10
- Amperage Operating Current
- 8mA when OFF; 13mA when ON
- Amperage Operating Current when changing state
- <7A (40 ms)
- Terminal Stud Torque
- 140 in-lb (15.82 Nm)
- Intermittent Rating
- 700A (5 min)
- Starting Rating 30 sec
- 1000A DC
- Minimum Operating Temperature
- -10° C
- Maximum Operating Temperature
- 60° C
- Cable Size to Meet Ratings
- 2x (4/0)
- Live Current Switching
- 300A @ 12V DC
- Master Control Switch Capability
- Yes
- Mechanical Endurance
- 100,000 Cycles
- Switching Rating
- 25A
- Terminal Ring Diameter Clearance
- 1.18in (29.97 mm)
- Terminal Stud Length
- 0.875in (22.23 mm)
- Terminal Stud Size
- 3/8" - 16 (M10)
Product details
- Voltage
- 12V DC
- Function
- ML-Solenoids
- Device Type
- ML-Solenoids
- Manufacturer
- Blue Sea Systems
- Product Type
- ML-Solenoids
What’s included
- 1×SPDT Remote Control Contura Switch - ON-ON
