Simrad NSS12 evo3S Combo MFD with C-MAP and HALO20+ Bundle (no HDMI video output)

SKU SIM-000-15555-002

Our Price$5,998.00

Usually ships 6-8 days

MFD display size: 12 inch
MFD display resolution: 800 x 1280
MFD dimensions (W x H x D): 352 x 225 x 98 mm; with bracket 377 x 241 x 120 mm
MFD weight: 3.1 kg
MFD maximum power consumption: 28 W
MFD supply voltage: 10 - 31.2 V DC
MFD waterproof rating: IPX6 and IPX7
Cartography and radar included: Preloaded C-MAP charts and HALO20+ radar

Contact us to confirm availability and shipping time. 30-day returns on unused stocked items. Exclusions apply. Return policy · Shipping policy

Shopping as a guest. Sign in to save your cart and check out as a dealer.

About this product

NSS12 evo3S bundle with a high-definition 12-inch display, preloaded C-MAP charts and HALO20+ radar, powered by an iMX 8 processor for charts, radar, sonar and more.

12-inch high-definition SolarMAX IPS display
iMX 8 high-performance processor
Built-in 1 kW CHIRP-enabled echosounder
Preloaded C-MAP charts
HALO20+ radar included
Touchscreen or keypad/rotary-dial operation

Manufacturer part number: 000-15555-002.

Verified product information

MFD display size: 12 inch
MFD display resolution: 800 x 1280
MFD dimensions (W x H x D): 352 x 225 x 98 mm; with bracket 377 x 241 x 120 mm
MFD weight: 3.1 kg
MFD maximum power consumption: 28 W
MFD supply voltage: 10 - 31.2 V DC
MFD waterproof rating: IPX6 and IPX7
Cartography and radar included: Preloaded C-MAP charts and HALO20+ radar
Internal storage: 16 GB

Product details

Weight: 3.1 kg (6.83 lb)
Screen Size: 12"
Supply Voltage: 10–31.2 V DC
Waterproof Rating: IPX6 and IPX7
Dimensions With Bracket: 377 x 241 x 120 mm (14.85 x 9.47 x 4.71 in)
Maximum Power Consumption: 28 W
Dimensions Without Bracket: 352 x 225 x 98 mm (13.84 x 8.87 x 3.82 in)
