Blue Sea Systems ST Blade Fuse Block - 6 Independent Circuits with Cover
SKU BLUE-5035
- Circuits
- 6
- Maximum Amperage
- 30A per circuit; 40A per jumped circuit group
- Maximum Voltage
- 32V DC
- Mounting
- #8 Screw (M4)
- Screw Terminal Torque
- 18 in-lb (2.03 Nm)
- Screw Terminal Type
- #8-32 with Captive Star Lockwasher
- Weight
- 0.35lb (0.16 kg)
- Voltage
- 32V DC
Stocked items typically ship the next business day from our US warehouse. 30-day returns on unused stocked items. Exclusions apply. Return policy · Shipping policy
Shopping as a guest. Sign in to save your cart and check out as a dealer.
About this product
ST Blade Fuse Block - 6 Independent Circuits with Cover. Corrosion resistant, tin-plated copper fuse clips reduce heat and improve the efficiency of the electrical system. Clear insulating cover with label recesses accepts Small Format Labels.
Key features
- Corrosion resistant, tin-plated copper fuse clips reduce heat and improve the efficiency of the electrical system
- Clear insulating cover with label recesses accepts Small Format Labels
- Spare fuse holder in cover
- Accepts ring or snap fork type terminals
- Includes two terminal block jumpers
For installation planning, check the manufacturer's ratings: maximum amperage: 30A per circuit; 40A per jumped circuit group; maximum voltage: 32V DC; mounting: #8 Screw (M4).
Manufacturer part 5035. Confirm the circuit rating, mounting arrangement, and required accessories against the manufacturer specifications before selecting this part.
Manufacturer specifications
- Circuits
- 6
- Maximum Amperage
- 30A per circuit; 40A per jumped circuit group
- Maximum Voltage
- 32V DC
- Mounting
- #8 Screw (M4)
- Screw Terminal Torque
- 18 in-lb (2.03 Nm)
- Screw Terminal Type
- #8-32 with Captive Star Lockwasher
- Weight
- 0.35lb (0.16 kg)
Product details
- Voltage
- 32V DC
- Function
- ST Blade
- Device Type
- ST Blade
- Manufacturer
- Blue Sea Systems
- Product Type
- ST Blade
