Blue Sea Systems 285-Series Circuit Breaker - Surface Mount 50A
SKU BLUE-7183
- Amperage
- 50A
- Maximum Voltage
- 48V DC
- Mounting
- Surface Mount
- Circuit Breaker Type
- Thermally responsive Bi-metal blade
- Terminal Stud
- M6 (accepts 1/4" Ring Terminal)
- Terminal Stud Torque
- 50 in-lb (5.65 Nm)
- Interrupt Capacity
- 3000A @ 48V
- Minimum Operating Temperature
- -40° C
Stocked items typically ship the next business day from our US warehouse. 30-day returns on unused stocked items. Exclusions apply. Return policy · Shipping policy
Shopping as a guest. Sign in to save your cart and check out as a dealer.
About this product
285-Series Circuit Breaker - Surface Mount 50A. Drop in replacement for 185-Series Circuit Breakers. Visible reset lever shows open condition.
Key features
- Drop in replacement for 185-Series Circuit Breakers
- Visible reset lever shows open condition
- Ignition protected - Safe for installation aboard gasoline powered boats
- Meets SAE J1171 external ignition protection requirements
- Weather Resistant
- Combines switching and circuit breaker function into one unit*
- "Trip Free" - cannot be held closed after trip
For installation planning, check the manufacturer's ratings: amperage: 50A; maximum voltage: 48V DC; mounting: Surface Mount.
Manufacturer part 7183. Confirm the circuit rating, mounting arrangement, and required accessories against the manufacturer specifications before selecting this part.
Manufacturer specifications
- Amperage
- 50A
- Maximum Voltage
- 48V DC
- Mounting
- Surface Mount
- Circuit Breaker Type
- Thermally responsive Bi-metal blade
- Terminal Stud
- M6 (accepts 1/4" Ring Terminal)
- Terminal Stud Torque
- 50 in-lb (5.65 Nm)
- Interrupt Capacity
- 3000A @ 48V
- Minimum Operating Temperature
- -40° C
- Maximum Operating Temperature
- 85° C
- Circuit Breaker Class
- Type III - switchable/manual reset - trip free
- Weight
- 0.50lb (0.23 kg)
Product details
- Series
- 285-Series
- Voltage
- 48V DC
- Function
- 285-Series
- Device Type
- 285-Series
- Manufacturer
- Blue Sea Systems
- Product Type
- 285-Series
- Mounting Style
- Surface Mount
